OEM / ODM ： Insert Injection Molding & Transparent Middle Frame (1*1) No.22448-B
| Place of Origin | Vietnam |
|---|---|
| Brand Name | Chitwing |
| Certification | ISO 9001:2015 |
| Model Number | Phone Case |
| Minimum Order Quantity | 1set |
| Price | Negotiable |
| Packaging Details | The mold is packaged with a wooden box and placed on a wood pallet. |
| Delivery Time | 30 day(s) |
| Payment Terms | L/C, T/T |
| Supply Ability | 180 set/month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Size | 400 X 450 X 426 | IMM Tonnage | 140T |
|---|---|---|---|
| Mold Weight | 470kg | Runner | Cold Runner |
| Mould Life | ≥500000 Shots | Design Software | 3D:UG 4.0, 2D:CAD |
| Mold Base | Custom Mold Base | Gate Type | Side Gate |
| High Light | Transparent Middle Frame Injection Mold,Three Plates Insert Injection Molding,Middle Frame Three Plates Mold |
||
Product Description
Transparent middle frame (1*1)
No.22448-B
| Firstly, this mold is designed with a reasonable structure that ensures uniform pressure distribution and minimizes stress concentration. It is meticulously crafted from clean steel, with a hardened cavity and core, resulting in exceptional hardness and anti-wearing performance. The tool life of this mold is impressive, lasting up to 5-10 years or 50,000 shots. |
| Secondly, this mold features a custom mold base, ensuring a tailored fit for specific requirements. It is a three-plates mold with a side gate, allowing for efficient and precise injection molding processes. The mold adheres to the LKM mold standard, guaranteeing high quality and reliability. With dimensions of 400mm in length, 450mm in width, and 426mm in height, and a net weight of 470kg, this mold stands as a substantial and robust tool. |
| Lastly, the mold boasts a polished surface finish, meeting the stringent SPI-A1 standards. It utilizes a cold runner injection/runner type, ensuring efficient material flow and minimizing waste. Notably, it is designed with 4 slides (cylinders) and the cavity and core hardness exceed 50HRC, guaranteeing precision and durability. This mold is specifically designed for injection molding with TPE material, with an injection part size of 150.4mm in length, 78.5mm in width, and 11.8mm in height. The injection part weighs 10g, making it suitable for various applications. |
